2007 Hummer H3 Stereo Wiring Diagrams

2007 Hummer H3 Car Stereo Speaker Wire Colors
Car Radio Battery Constant 12v+ Wire: Orange
Car Radio Accessory Switched 12v+ Wire: N/A
Car Radio Ground Wire: Black/White
Car Radio Illumination Wire: N/A
Car Stereo Dimmer Wire: N/A
Car Stereo Antenna Trigger Wire: N/A
Car Stereo Amp Trigger Wire: Pink
Car Stereo Amplifier Location: Located behind the trim in the left side of cargo area next to subwoofer.
Car Audio Front Speakers Size: N/A
Car Audio Front Speakers Location: N/A
Left Front Speaker Positive Wire (+): Tan
Left Front Speaker Negative Wire (-): Dark Green
Right Front Speaker Positive Wire (+): Light Green
Right Front Speaker Negative Wire (-): Orange/Black
Car Audio Rear Speakers Size: N/A
Car Audio Rear Speakers Location: N/A
Left Rear Speaker Positive Wire (+): Brown
Left Rear Speaker Negative Wire (-): Dark Green/White
Right Rear Speaker Positive Wire (+): Dark Blue
Right Rear Speaker Negative Wire (-): Black
