Car Stereo Wiring Diagrams

2007 Mini Cooper S

2007 Mini Cooper S Car Stereo Wiring Diagram

Car Radio Battery Constant 12v+ Wire: Red/Brown
Car Radio Accessory Switched 12v+ Wire: Violet/Blue
Car Radio Ground Wire: Brown
Car Radio Illumination Wire: Gray/Red
Car Stereo Dimmer Wire: N/A
Car Stereo Antenna Trigger Wire: White
Car Stereo Amp Trigger Wire: White
Car Stereo Amplifier Location: Full range amp is behind trim in right rear cargo area.
Car Audio Front Speakers Size: N/A
Car Audio Front Speakers Location: N/A
Left Front Speaker Positive Wire (+): Yellow/Red (These wires also go to the front tweeter.)
Left Front Speaker Negative Wire (-): Yellow/Brown
Right Front Speaker Positive Wire (+): Brown/Black (These wires also go to the rear tweeter.)
Right Front Speaker Negative Wire (-): Blue/Black
Car Audio Rear Speakers Size: N/A
Car Audio Rear Speakers Location: N/A
Left Rear Speaker Positive Wire (+): Yellow/Black
Left Rear Speaker Negative Wire (-): Yellow/Gray
Right Rear Speaker Positive Wire (+): Blue/Violet
Right Rear Speaker Negative Wire (-): Blue/Gray
