1993 Acura Integra Car Stereo Wiring Diagram :
- 1993 Acura Integra Car Stereo Radio Wiring Diagram
- Car Radio Constant 12V+ Wire: Blue/White
- Car Radio Switched 12V+ Wire: Yellow/Red
- Car Radio Ground Wire: Black
- Car Radio Illumination Wire: Red/Black
- Car Stereo Dimmer Wire: N/A
- Car Stereo Antenna Trigger: Yellow/White
- Car Stereo Amp Trigger Wire: N/A
- Front Speakers Size: 5 1/4? Speakers
- Front Speakers Location: Doors
- Left Front Speaker Positive Wire (+): Blue/Green
- Left Front Speaker Negative Wire (-): Gray/Black
- Right Front Speaker Positive Wire (+): Red/Green
- Right Front Speaker Negative Wire (-): Brown/Black
- Rear Speakers Size: 6 1/2? Speakers
- Rear Speakers Location: Side Panels
- Left Rear Speaker Positive Wire (+): Blue/Yellow
- Left Rear Speaker Negative Wire (-): Gray/White
- Right Rear Speaker Positive Wire (+): Red/Yellow
- Right Rear Speaker Negative Wire (-): Brown/White
