2011 Honda Fit Stereo Wiring Diagrams
About 2011 Honda Fit
- 2011 Honda CR-V
- Compact sport utility vehicle
- MPG: Up to 21 city, 28 highway
- Towing capacity: 1,500 lbs
- Horsepower: 180 HP
- Cargo volume: 35.7 ft?, 72.9 ft? with seat area
- Other model years: 2009, 2010, 2012, 2013
2011 Honda Fit Stereo Wiring Diagrams :
- 2011 Honda CRV Car Audio Wiring Schematic
- Car Radio Battery Constant 12v+ Wire: Orange
- Car Radio Accessory Switched 12v+ Wire: White
- Car Radio Ground Wire: Black
- Car Radio Illumination Wire: Gray
- Car Stereo Dimmer Wire: Red
- Car Stereo Power Antenna Trigger Wire: Black
- Car Stereo Amp Turn-On Trigger Wire: N/A
- Car Stereo Amplifier Location: N/A
- Car Audio Front Tweeter Size: 1? Tweeters
- Car Audio Front Tweeter Depth: 2?
- Car Audio Front Tweeter Location: N/A
- Left Front Speaker Positive Wire (+): Light Green
- Left Front Speaker Negative Wire (-): Green
- Right Front Speaker Positive Wire (+): White
- Right Front Speaker Negative Wire (-): Yellow
- Car Audio Front Speakers Size: 6 1/2? Speakers
- Car Audio Front Speakers Depth: 3?
- Car Audio Front Speakers Location: N/A
- Left Rear Speaker Positive Wire (+): Gray
- Left Rear Speaker Negative Wire (-): Brown
- Right Rear Speaker Positive Wire (+): Blue
- Right Rear Speaker Negative Wire (-): Orange
- Car Audio Rear Speakers Size: 6 1/2? Speakers
- Car Audio Rear Speakers Depth: 3?
- Car Audio Rear Speakers Location: N/A
- Car Subwoofer Speaker Size: N/A
- Car Subwoofer Speaker Depth: N/A
- Car Subwoofer Speaker Location: N/A
- Car Subwoofer Speaker Positive Wire (+): N/A
- Car Subwoofer Speaker Negative Wire (-): N/A
