1986 Mercury Cougar Car Stereo Wiring Diagram :
- 1986 Mercury Cougar Car Stereo Wire Schematic
- Car Radio Battery Constant 12v+ Wire: Green/Yellow
- Car Radio Accessory Switched 12v+ Wire: Yellow/Black
- Car Radio Ground Wire: Chassis
- Car Radio Illumination Wire: Blue/Red
- Car Stereo Dimmer Wire: N/A
- Car Stereo Antenna Trigger Wire: Orange/Blue
- Car Stereo Amp Trigger Wire: N/A
- Car Stereo Amplifier Location: N/A
- Car Audio Front Speakers Size: 3 1/2?
- Car Audio Front Speakers Location: Dash
- Left Front Speaker Positive Wire (+): Orange/Green
- Left Front Speaker Negative Wire (-): Black/White
- Right Front Speaker Positive Wire (+): White/Green
- Right Front Speaker Negative Wire (-): Black/White
- Car Audio Rear Speakers Size: 6? x 9? Speakers
- Car Audio Rear Speakers Location: Rear Deck
- Left Rear Speaker Positive Wire (+): Pink/Green
- Left Rear Speaker Negative Wire (-): Pink/Blue
- Right Rear Speaker Positive Wire (+): Pink/Blue
- Right Rear Speaker Negative Wire (-): Green/Orange
