1987 Mitsubishi Starion Stereo Wiring Diagrams :
- 1987 Mitsubishi Starion Car Audio Wiring Diagram
- Car Radio Battery Constant 12v+ Wire: Red/Black
- Car Radio Accessory Switched 12v+ Wire: Blue
- Car Radio Ground Wire: Chassis
- Car Radio Illumination Wire: Black/Yellow
- Car Stereo Dimmer Wire: N/A
- Car Stereo Antenna Trigger Wire: White/Black
- Car Stereo Amp Trigger Wire: N/A
- Car Stereo Amplifier Location: N/A
- Car Audio Front Speakers Size: N/A
- Car Audio Front Speakers Location: N/A
- Left Front Speaker Positive Wire (+): White/Blue
- Left Front Speaker Negative Wire (-): Black/Blue
- Right Front Speaker Positive Wire (+): White/Red
- Right Front Speaker Negative Wire (-): Black/Red
- Car Audio Rear Speakers Size: N/A
- Car Audio Rear Speakers Location: N/A
- Left Rear Speaker Positive Wire (+): Yellow/Blue
- Left Rear Speaker Negative Wire (-): Gray/Blue
- Right Rear Speaker Positive Wire (+): Yellow/Red
- Right Rear Speaker Negative Wire (-): Gray/Red
