1997 Mitsubishi Eclipse Stereo Wiring Diagrams
About 1997 Mitsubishi Eclipse
- 1997 Mitsubishi Eclipse
- Sports car
- Engine: 2.0L 4-cylinder
- MPG: Up to 23 city, 31 highway
- Horsepower: 140 to 210 HP
- Curb weight: 2,844 to 3,208 lbs
- Other model years: 1995, 1996, 1998, 1999
1997 Mitsubishi Eclipse Stereo Wiring Diagrams :
- 1997 Mitsubishi Eclipse Car Audio Wiring Diagram
- Car Radio Battery Constant 12v+ Wire: Red/Black
- Car Radio Accessory Switched 12v+ Wire: Blue
- Car Radio Ground Wire: Chassis
- Car Radio Illumination Wire: Green/White
- Car Stereo Dimmer Wire: Black/Yellow
- Car Stereo Antenna Trigger Wire: White/Black
- Car Stereo Amp Trigger Wire: N/A
- Car Stereo Amplifier Location: N/A
- Car Audio Front Speakers Size: 5 1/4? Speakers
- Car Audio Front Speakers Location: Doors
- Left Front Speaker Positive Wire (+): Black/White
- Left Front Speaker Negative Wire (-): Black
- Right Front Speaker Positive Wire (+): Black/White
- Right Front Speaker Negative Wire (-): Black
- Car Audio Rear Speakers Size: 6? x 9? Speakers
- Car Audio Rear Speakers Location: Side Panels
- Left Rear Speaker Positive Wire (+): Yellow/Blue
- Left Rear Speaker Negative Wire (-): Gray/Blue
- Right Rear Speaker Positive Wire (+): Yellow/Red
- Right Rear Speaker Negative Wire (-): Gray/Red
