1994 Oldsmobile Cutlass Supreme Stereo Wiring Diagrams
About 1994 Oldsmobile Cutlass Supreme
- 1994 Oldsmobile Cutlass Supreme
- Mid-size car
- MPG: Up to 19 city, 29 highway
- Horsepower: 160 to 210 HP
- Fuel tank capacity: 16.5 gal
- Other model years: 1992, 1993, 1995, 1996
- Engine: 3.1L V6, 3.4L V6
1994 Oldsmobile Cutlass Supreme Stereo Wiring Diagrams :
- 1994 Oldsmobile Cutlass Supreme Car Stereo Wiring Diagram
- Car Radio Battery Constant 12v+ Wire: Orange
- Car Radio Accessory Switched 12v+ Wire: Yellow
- Car Radio Ground Wire: Black
- Car Radio Illumination Wire: Gray
- Car Stereo Dimmer Wire: Brown
- Car Stereo Antenna Trigger Wire: Pink
- Car Stereo Amp Trigger Wire: N/A
- Car Stereo Amplifier Location: N/A
- Car Audio Front Speakers Size: 4? Speakers
- Car Audio Front Speakers Location: Dash
- Left Front Speaker Positive Wire (+): Tan
- Left Front Speaker Negative Wire (-): Gray
- Right Front Speaker Positive Wire (+): Light Green
- Right Front Speaker Negative Wire (-): Dark Green
- Car Audio Rear Speakers Size: 6? x 9? Speakers
- Car Audio Rear Speakers Location: Rear Deck
- Left Rear Speaker Positive Wire (+): Brown
- Left Rear Speaker Negative Wire (-): Yellow
- Right Rear Speaker Positive Wire (+): Dark Blue
- Right Rear Speaker Negative Wire (-): Light Blue
